Multimodal Attention-based CNNs for the Prediction of Alzheimer’s Disease
The brain is amazingly complex. It’s made up of more than 86 billion nerve cells and it’s what makes us, well.. us! But when problems occur in the brain and how it functions, debilitating conditions which can take away our ability to do simple things arise. One of these conditions is known as Alzheimer’s Disease.
Alzheimer’s disease (AD) is a neurodegenerative condition characterised by memory impairment and cognitive decline. It’s one of the most prevalent neurodegenerative diseases, and unfortunately, there’s no current cure for it. This means that current treatment processes revolve around delaying the onset of symptoms. So, it’s pretty important to detect the presence of the AD as soon possible to ensure early treatment. But this is hard. The underlying factors which cause the disease are very complex and still not very well understood. So this brings up the question, is there a way we can effectively detect the presence of AD in individuals when we don’t fully know the defining patterns or features relating to brains with AD? The answer:
Convolutional Neural Networks!
In this project, we present MNA-net, a Multimodal Neuroimaging Attention-based convolutional neural network (CNN). Instead of simply classifying whether someone has AD, we focus on predicting the progression of the disease, that is, predict whether a cognitively normal individual will develop AD or some form on mild cognitive impairment (MCI) in the future. To learn the complex features relating to MCI and AD, MNA-net combines both Magnetic Resonance Imaging (MRI) and Positron Emission Tomography (PET) using attention-based mechanisms.
Dataset
For this project, we use the OASIS-3 dataset obtained from the Open Access Series of Imaging Studies (OASIS). OASIS was launched in 2007 with the primary goal of making neuroimaging data publicly available for study and analysis. OASIS-3 is a longitudinal dataset released as a part of OASIS in 2018. It is a compilation of clinical data and MRI and PET images of multiple subjects at various stages of cognitive decline collected over the course of 30 years. Subject cognitive states in OASIS-3 are defined by clinical dementia rating (CDR) scores. A total of 1378 participants entered the study, 755 of which were cognitively normal (CDR = 0), and 622 who were at progressing stages of cognitive decline (CDR ≥ 0.5). For our study, we will utilise the MRI and PIB PET images provided in OASIS-3.
Subject Selection
To predict the progression of cognitive impairment in individuals within OASIS-3, we focus on two groups of subjects: subjects who remained cognitively normal (CN), and subjects transitioned from CN to MCI or AD over the course of the study in OASIS-3. For this scope of this work, we consider a timeframe 10 years. One important point to keep in mind is the temporal alignment of data. It’s important that subject scans are taken within close proximity of their initial diagnosis so that scans are representative of their cognition at the time of their baseline. Taking these factors into consideration, our subject selection criteria for the OASIS-3 dataset are as follows:
- Subjects were diagnosed as CN at baseline.
- Subjects have taken MRI and PET scans that are within a year from their baseline diagnosis.
- Of CN subjects who developed cognitive impairment over the course of the study, only those who were diagnosed with MCI or AD within 10 years of their baseline diagnosis were considered.
- Of subjects who remained CN over the course of the study, only those who received a diagnosis of CN at least 10 years after their baseline diagnosis were considered.
Image Data
Post processed Freesurfer files for the MRI images are provided by OASIS-3. These files contain the subject-specific 3D MRI images which have undergone skull stripping. The PIB PET images, however, are provided as 4D Nifti files. These images are acquired in multiple frames over different time intervals and as such, we apply temporal averaging of the 4D PET images to average the frames into static 3D images. Noise and skull is then need to be removed from the PET images using Brain Extration Tool (BET) and Synthstrip. Figure 3 presents an example of PET noise and skull removal.
Skull and noise removal of PET image
Finally, both MRI and PET images are standardised and aligned to a common anatomical template by normalising voxel intensities and registering them to Montreal Neurological Institute (MNI) space using FMRIB’s Linear Image Registration Tool (FLIRT)
Data augmentation is performed on the training set to increase the dataset size. To simulate different positions and size of the patient within the scanner, and anatomical variations present in the images, random affine transformations and elastic deformations were applied to the images. The figure below shows examples of elastic deformations and affine transforms applied to an MRI image.
From left to right: Control MRI, Elastic Deformation, Affine Transformation
MNA-net
To harness the strengths of both MRI and PET in CN to MCI and AD classification, we propose MNA-net, a multimodal neuroimaging attention-based CNN. We define three stages in the classification process in MNA-net as shown in the figure below: patch feature extraction, multimodal attention, and patch fusion.
In the first stage, we adopt a patch-based technique. MRI and PET images are both divided into 27 uniform patches of size 44 x 54 x 44 with 50% overlap. Each patch is then fed into a 3D ResNet-10 model to extract the local features of each image. By dividing the neuroimages into patches, we allow MNA-net to more effectively capture the local features in each patch location.
In the second stage of the classification process, we introduce an attention-based ensemble architecture to facilitate the fusion of the different neuroimaging modalities. For every patch in corresponding positions between the MRI and PET patches, we extract the learnt features from the ResNet-10 models and pass them through an attention-based model. This model utilises self-attention mechanisms to enable the model to create shared representations of the MRI and PET features.
In the final stage, we consolidate the features extracted from the patch-level models. The attention weighted multimodal features for each patch are extracted from the attention models and flattened, concatenated, and passed through a dense with sigmoid activation for the final classification.
Due to the complexity and wideness of the architecture, training MNA-net as a single model is computationally intensive. Instead, we train the individual models for each classification stage separately. Features are extracted from each model and used as inputs for the subsequent classification stage.
Patch-based Feature Extraction
To extract the patch-based features, we adopt a 3D ResNet architecture as the backbone model. ResNet is family of CNN architectures which introduce the concept residual connections. ResNet aims to overcome the issue of exploding and vanishing gradients seen in deep networks.
The major limitation of many CNN architectures applied in the prediction of cognitive decline is use of 2D kernels. To accommodate PET and MRI scans within the framework of 2D CNNs, the 3D brain images are often divided into multiple 2D slices. However, this results in a loss of spatial information. To this end, we instead utilise a 3D ResNet architecture using 3D convolutions. A brief illustration of the model is shown in the figure below.
The patch images of size 44x54x44 are first passed through a 7x7x7 convolutional layer with stride 2 and padding 3, followed by max pooling, batch normalisation, and a ReLu. We then introduce the residual connections through four sequential conv blocks. Each conv block consists of two 3x3x3 convolutional layers, each followed by batch normalisation and Relu. A residual connection is included between the beginning of the block and the layer preceding the final ReLu. Strides of 2 are used in the convolutional layers of conv block 2, conv block 3, and conv block 4 to perform down sampling. The output feature maps of conv block 4 are then finally subjected to an average pooling layer, flattened, and subsequently passed through a fully connected layer for final classification. The features prior to the final dense and sigmoid layers are extracted and used as inputs for the multimodal attention classification stage.
Attention-based Multimodal Feature Fusion
To combine the learned patch features of MRI and PET, we introduce the concept of self-attention into our fusion pipeline. Previous works which combine PET and MRI images for MCI and AD classification simply involved the concatenation of the learned features. Theres a limitiation to this however due to the lack of cross-modal interactions. Representations of MRI and PET features which take into account information from each other may be more informative than considering each feature independently. Attention mechanisms aim to mimic the cognitive process of attention, enabling neural networks to create shared representations which consider all parts of the input data based on attention scores. To understand the concept more intuitively, we can liken it to the understanding of a word in the context of a sentence. For example, lets look at the following sentence:
The dog barked loudly and jumped.
If we just focus on the word barked by itself, it doesn’t really have much meaning, does it? Who exactly barked? How did they bark? Conversely, if we now focus on the word barked placing attention to all the words in the sentence, we now have a much better understanding. It was the dog who barked, and they barked very loudly. Now this is where the attention aspect comes in. To understand the context of the word barked, we don’t necessarily place the same emphasis on all the words in the sentence. In this case, we place more attention onto words dog and loudly, with the remaining words less so.
When we combine the PET and MRI features, we don’t want to just focus on each modality individually. Certain aspects of the PET features may reinforce or complement features in the MRI images and vice versa. What attention mechanisms allow us to do, is create shared representations of each modality, similar to how we combine all words (to an extent) in a sentence to understand the context of a word. These shared representations of the modalities provide much more meaninful information to aid in the final classification process. The figure below shows the architecture of the attention model trained to fuse the patch features.
For every patch in corresponding positions between the MRI and PET patches, we extract and vertically stack the features prior to the last layer from the previously trained patch-based feature extraction models. We then pass the stacked features through a multi-head attention layer with 4 attention heads. Finally, the vertically stacked attention weighted outputs for the PET and MRI features are flattened and passed through a fully connected layer for final classification. The final flattened features are then used as inputs to the final model.
